Advanced Style-Data Cooptimization

Together with the Techical Unversity of Munichs’ chair of Big Geospatial Data Management, we are currently working on a thesis where the next generation of vector tile performance from tile servers could come from:

  • At the minimum, the outcome of this initiative will be a documentation page detailing which aspects of vector tiles are not improving performance and why.performance
  • At best, the outcome will be a new optimised mode for serving styles and the data in a co-optimzed fassion.

Here are the optimisations that are currently planned for evaluation:

optimisationrequirementdescription (technique)
dead source elimination-remove impossible or hidden data-sources or style-layers (dead code elimination)
expression order optimisationsamplingoptimise the order of reorderable-expressions (like match) (selectivity analysis)
expression kind optimisation-rewrite expensive operators with more performant forms (operator selection)
constant foldingfull scanreplace constant style expressions or predicates with literal values (constant folding)
filter reorderingsamplingoptimize style filter order (like any, all, match, case) (selectivity analysis)
metadata refinementfull scanmore accurate {min,max}_zoom metadata based on the data, filters, and impossible styling conditions (think: opacity=0 after zooming out) (no exact match)
tile shaving-only encodes the exact data that a style would actually look at (no exact match)
transparent reencoding-reencode tiles into a different tile specification on the fly (storage format)
compression optimisation-compress tiles more aggressively or with a different compression algorithm (no exact match)
prewarming caches-make sure that sprites and fonts are in an in-memory cache (prefetching)
minimum sprite-set mining- / full scansome styles may permit to statically know which sprites will be used. For others, one might need to do a full table scan to gather this statistic. (no exact match)
data layout optimisation-for dynamic databases, reorganise tile data for access pattern (storage layout)
overlap reduction-for some layers like roads or pois at the higher zoom levels overlap is common. If one knows the style redundant data can be removed (storage layout)
static generationstatic sourceextract semantics and generate a new, optimal static instruction set for constructing the tile database

List of some possible optimisations. full scan means that this optimisation would require executing one operation over the whole table at minimum. sampling means that this data can be gathered by sampling approaches, but evaluating if a full scan could add context will have to be looked at. For sampling-based approaches, the resampling frequency for the dynamic sources noted in \cref{access:dynamic} needs to be determined via statistical approaches. The cases where no scan is necessary does not mean that it might not still be beneficial, for example for parameter tuning.

GitHub Issues: #1757
